1. It’s with the most advanced fingerprint arithmetic in the world, it can analyze the tiny differences between the latest fingerprints and the previous ones and update automatically. Thus, the fingerprint recognition is with high accuracy and optimum speed. It's also with high recognition ability for injured and peeled fingers that the identification time is less than 1s.
2. The device is built-in ID card sensor (optional for IC card), validate freely by Card, fingerprint and password combination, Access control is more flexible and securely With multi-level validation, lock combination and anti-pass back function, it suitable to the high-security places like bank and military etc.
3. Support U disk to download or upload attendance records and fingerprint data. User could enroll the fingerprint in one device, and share the enrollment information with other devices through the USB flash memory.
4. TCP/IP communication, It is very simple and easy to setup. you can access attendance log, report & all settings within the network.

• Fingerprint Access Control & Time Attendance
• LCD Screen: 2.4 inch TFT (320*240) Color Screen
• Color: Black
• Fingerprint Sensor Resolution: 500DPI (Optical sensor)
• Communication: TCP/IP, USB Memory Disk, RS485
• User Capacity: 800 templates
• Records Capacity: 50,000
• Hardware Platform: ZDC2911
• Software OS: XP/Win2003/Vista/Win7/Win8 /Win10 (32bit / 64bit)
• Identification Time: < 1 S
• Authentication Method: Fingerprint, ID Card
• Language: English (Spanish, Polish, Arabic, Turkish, could customize others)
• Bell: Built-in Timing Bell (Scheduled-bell) + External Belling
• Access Control Interface: 3rd Party Electric Lock, Exit Button, Wiegand(26/34) in/out, Door Bell, Relay output (one set Lock relay output, one set alarm
• relay output)
• Power: DC 12V/3A
• Operating Mode: Off-line/On-line
• Operating environment: Operating Temp: 0℃ ~ 45℃, Humidity: 20% ~ 80%
• Certificates: CE, Type Inspection Report of Chinese Police Product
• Dimension(L*W*H)mm: Terminal: 103*103*31mm
• Weight: Terminal + Package: 0.5KG
